Dahua monitor LM22-A210Y 21,4" VA/­1920x1080/­5ms/­250nits/­3500:1/­HDMI/­VGA/­černý

Display

Model


DHI-LM16-F201PD

LCD Technology


IPS

Backlight


ELED

Screen Size


15.6 inch

Aspect Ratio


16:9

Viewing Size


344.16 (H) × 193.59 (V) mm

Screen-to-Body Ratio


?80%

Viewing Angle


178° (H)/178° (V)

Display Mode


Horizontal

Pixel Pitch


0.17925 mm × 0.17925 mm (0.00706" × 0.00706")

Pixels Per Inch


141.21

Resolution


1920 (H) × 1080 (V)

Refresh Rate


60 Hz

Display Color


16.7M colors (6 bits + FRC)

Color Gamut


45% NTSC

Brightness


250 cd/m2 (max)

Contrast Ratio


1000:1

Response Time


6 ms

Lifespan


30,000 hrs

Operation Hours


7 × 16 H

Surface Treatment


Haze 25%, 3H

Low Blue Light


Software blue light protection

Device Ports

Input Port


2 x TYPE-C (full-function), 1 x HDMI 1.4 (1920 x 1080@60 Hz)

Output Port


1 × Audio out

Speaker


2 × 1 W

Power & Environmental Conditions

Power Supply


5 VDC, 3 A

Power Type


External power adapter (without adapter)

Power Consumption


7.5 W (basic), 7.5 W (typ.), 8.2 W (max)

Standby Power Consumption


<0.5 W

Operating Temperature


0 °C to +40 °C (+32 °F to +104 °F)

Operating Humidity


10% - 85% (RH)

Storage Temperature


–20 °C to +60 °C (–4 °F to +140 °F)

Storage Humidity


5% - 90% (RH)

General

Inclined Angle


90°

Product Dimensions


358.0 mm × 226.4 mm × 12.1 mm (14.09" × 8.91" × 0.48") (W × H × D)

Package Size


398 mm × 283 mm × 59 mm (15.67" × 11.14" × 2.32") (W × H × D)

Frame Width


U/L/R/D: 6.7 mm/6.7 mm/6.7 mm/22.8 mm(0.26" / 0.26" / 0.26" / 0.90")

Net Weight


0.73 kg (1.63 lb)

Gross Weight


1.3 kg (2.87 lb)

Casing Color


Black

Control Mode


Four-button

Status Indicator Light


Yes

Wall Mount VESA


75 mm (2.95")

Accessory


Type-C cable (full-function), HDMI cable, user manual (QR code sticker), QSG, regulatory manual, energy efficiency label, storage bag

Optional Accessory


Wall mount
